INDIAN ELEVATOR TECHNOLOGY

ALL THE BEST FROM MY TEAM COMPANY NAME – “SCHINDLER INDIA PRIVATE LIMITED” DATE – 25 TH JANUARY 2019 OPENING – CUSTOMER ENGINEER (EXISTING INSTALLATION) EXPERIENCE – MINIMUM 2 YEARS (ELEVATOR SERVICE & MAINTENANCE) FRESHER ARE WELCOME FOR INTERVIEW QUALIFICATION – DIPLOMA/ITI TIME – 10AM – 12PM ADDRESS – SCHINDLER INDIA PRIVATE LIMITED, 4 TH FLOOR, AGRAWAL TRADE CENTRE, SECTOR -11, CBD-BELAPUR. NAVI MUMBAI

COMPANY NAME – ‘KONE INDIA PRIVATE LIMITED’ ABOUT COMPANY - TOP COMPANY IN ELEVATOR INDUSTRY & BEST FACILITIES FOR WORKERS POSITION NAME – “INSTALLERS” QUALIFICATION – ITI / DIPLOMA (MECHANICAL, ELECTRICAL ETC) EXPERIENCE  – FRESHER ALSO WELCOME INTERVIEW DATE – 15 TH JAN 2019 TO 17 TH JAN 2019. ADDRESS – KONE ELEVATOR INDIA PRIVATE LIMITED,SILVER UTOPIA,B-WING, 8 TH FLOOR,CARDINAL GRACIOUS ROAD,CHAKALA,ANDHERI (E). MUMBAI – 400099                                                                           CONTACT NUMBER – 02267713276

CLEARANCE CHART IN ELEVATOR   (all dimension are in mm) Brake stroke adjustment – 0.5 to 1 mm Final limit switch top-bottom – 150 mm Sheave rope guard – 3 to 5 mm Gear oil level – between minimum to maximum Rope slip – ½ meter Guide shoe clearance(car) – 2 to 3 mm Guide shoe clearance (counter weight) – 3 to 5 mm Car-counterweight rope guard clearance – 5 mm Counter weight runby – 300 to 350 mm Car runby – 300 to 320 mm Running clearance (auto door) – 30 mm Running clearance (manual) – 25mm Safety gear block to guide rail – 2mm Safety switch electrical – 3 mm                    Note - these is not the standard chart but similar to it

The first ever elevator installed in India was in the heritage building of Raj Bhavan at kolkata by Otis Elevator Company India in 1892

what is SAFETY....?? in a simple words its means keeping yourself and other free from harm & danger

what is the difference between LIFT & ELEVATOR ...?? both are same name given by country is different ELEVATOR in the USA . LIFT in the BRITAIN

One of the first elevators that was intended for passenger use was installed in French king Luis XV’s villa at Versaille s

The first ever elevator installed in India was in the heritage building of Raj Bhavan at kolkata by Otis Elevator Company India in 1892

Elevator music first appeared in 1920s to calm the fearful passengers who used the elevators for the first time.

ELEVATOR MACHINE ROOM (M/R) SAFETY: *Elevator (M/R) shall be kept locked & unauthorized persons NOT allowed to enter. *All rotary/moving parts shall be guarded. *Safety signage on door. *Yellow demarcation line around machines. *Identification number tag on each Elevator.

what is SPEED GOVERNORS...?? The speed regulating system of elevators is known as the speed governor. If the elevator runs more than the speed limit, the speed governor controls the speed. It is usually attached to the bottom of the car and is also known as governor rope.

1) MC -- Magnetic Contactor 2) NO -- Normally Open 3) NC-- Normally Close 4) AVR -- Automatic Voltage Regulator 5) VFD -- Variable Frequency Drive 6) MCB -- Miniature Circuit Breaker 7) MCCB -- Molded Case Circuit Breaker 8 ) HT -- High Tension 9) LT --Low Tension 10) ATS -- Automatic Transfer Switch 11) DB -- Distribution Board 12) SDB -- Sub Distribution Board 13) VCB -- Vaccum Circuit Breaker 14) ACB --Air Circuit Breaker 15) BBT -- Bus Bar Trunking System 16) MPCB -- Motor Protection Circuit Breaker 17) DOF -- Drop Out Fuse 18) PFI -- Power Factor Improvement 19) HRC Fuse-- High Rupturing Capacity 20) L1, L2, L3 -- Supply Coil in three phase system 21) R, S, T -- Input terminal of supply coil 22) U, V, W -- Output terminal of Supply Coil 23) LBS --Load Break Switch 24) ELCB -- Earth leakage Circuit Breaker 25) RCCB -- Residual Current Circuit Breaker 26) OCB --Oil Circuit Breaker 27) PLC --Programmable Logic Controll

how to cancelled wrong floor button If you press a wrong floor button, by double-press it or pressing for seconds you can cancel it. if these cancellation is not done then its an old system
